Tennis court dimensions
78 ft long (23.77 m) · 36 ft doubles / 27 ft singles wide
A tennis court is 78 feet (23.77 m) long for every match — what changes is the width: 27 feet (8.23 m) for singles and 36 feet (10.97 m) for doubles, thanks to the 4.5-foot alleys on each side. These are the official ITF dimensions, the service boxes, the net heights and how much total space a court really needs.
To-scale diagram · official dimensions per ITF (Rules of Tennis)
Official dimensions
| Element | Measurement | Detail |
|---|---|---|
| Court length | 78 ft (23.77 m) | same for singles and doubles |
| Width (doubles) | 36 ft (10.97 m) | includes both alleys |
| Width (singles) | 27 ft (8.23 m) | without the alleys |
| Service line | 21 ft (6.40 m) | from the net |
| Service boxes | 21 × 13.5 ft (6.40 × 4.115 m) | two on each side |
| Net height (center) | 3 ft (0.914 m) | |
| Net height (at posts) | 3.5 ft (1.07 m) | posts 3 ft outside the doubles sideline |
| Doubles alley | 4.5 ft (1.37 m) | on each side |
Court zones explained
The service boxes. Each side has two boxes of 21 × 13.5 ft between the net and the service line. The serve must bounce in the box diagonally opposite the server.
The doubles alleys. The 4.5 ft strips along each side. They are in play only during doubles — in singles the inner sideline rules.
The baseline. The back boundary, 39 ft (11.885 m) from the net. Its short center mark splits the deuce and ad sides for serving position.
The net. 3 ft high at the center and 3.5 ft at the posts, which stand 3 ft outside the doubles sidelines.
Surface and materials
Four official surface families: hard (acrylic over asphalt/concrete — used at the US Open and Australian Open), clay (Roland Garros), grass (Wimbledon) and artificial/carpet. Each surface changes ball speed and bounce, which is why playing styles differ so much across them.
Variants and categories
| Singles court | 78 × 27 ft (23.77 × 8.23 m) — no alleys. |
|---|---|
| Doubles court | 78 × 36 ft (23.77 × 10.97 m) — with alleys. |
| Recommended total area | Room behind the baselines and beside the sidelines is required for play; competition venues run roughly 120 × 60 ft overall. |
| Pickleball (not the same!) | A different sport: its court is only 20 × 44 ft — four of them fit on one tennis court. |
Looking for a place to play tennis?
Find tennis courts near meFrequently asked questions
How long is a tennis court?
A tennis court is 78 feet (23.77 m) long from baseline to baseline, for both singles and doubles.
How wide is a tennis court?
27 feet (8.23 m) for singles and 36 feet (10.97 m) for doubles — the extra width comes from the two 4.5 ft alleys.
How high is a tennis net?
The net is 3 feet (0.914 m) high at the center and 3.5 feet (1.07 m) at the posts.
How far is the service line from the net?
The service line runs 21 feet (6.40 m) from the net on each side, closing the four service boxes.
